Webelos – 4th Grade
Build It
Elective
Requirement 2

Doorway Plumb, Level, and Square

Webelos – 4th Grade
Build It
Elective
Requirement 2

Doorway Plumb, Level, and Square

Snapshot of Activity

Cub Scouts check a door frame for plumb, level, and square.

Indoor
3
3
2
If you want to know more about The Adventure Activity Key click here.
  • Door that will stand open
  • Measuring tape at least 10 feet long
  • Level
  • Plumb, Level, Square door diagram found in Additional Resources

Before the meeting:

  1. Gather supplies.
  2. Familiarize yourself with the concepts of plumb, level, and square.  Recommended video – Plumb vs. Level vs. Square  (6 min. 19 sec.) and review the diagram Plumb, Level, Square door diagram in Additional Resources .
  3. Set up meeting space with access to a door to demonstrate plumb, level, and square.

During the meeting:

  1. Gather Cub Scouts around a door that will stand open. Explain to them that doors are a great way to understand plumb, level, and square. A door must be all 3 to work properly. A door hangs in a door frame.
  2. Plumb refers to both the lock side and the hinge side of the door being truly vertical.
  3. Level refers to the door top and bottom being level within the door frame.
  4. The door must be square within the frame to open and close correctly.
  5. Have Cub Scouts take a vertical measurement for plumb:
    • Open door. Place level against the inside jam.
    • Check to see if bubble is center between the lines.
    • Check the opposite side of the door for the same.
    • Take a second vertical measurement by doing the same vertical measurement using the outer edge of the jam.
  6. Have Cub Scouts take a horizontal measurement for level:
    • Place level along the top of the door.
    • Check to see if bubble is center between the lines.
    • Do the same with the base or threshold of the door.
  7. And finally, check for square, each corner must be at perfect right angles.
    • Place the end of the Measuring tape where the doorframe meets the threshold.
    • Run the Measuring tape diagonally to the corner of the top of the door frame. (See Plumb, Level, Square door diagram)
    • Hold the Measuring tape taut and record the measurement.
    • Starting at the opposite corner take the Measuring tape and measure from the bottom corner where the frame meets the threshold diagonally to the upper corner. Record the measurement.
    • If the two measurements are the same the door is square. If they are not the same, you may be experiencing some issues with the door.

Additional Resources

Plumb, Level, Square door diagram
